Product Details
Place of Origin: China
Brand Name: Tianniu
Certification: ISO-9001
Model Number: GCZ-A series
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Cartons by sea shipping by airplane
Delivery Time: 5-10working days
Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability: 10000 per month
Name: |
GCZ-A One Direction Bearing Roller Type Clutch |
Material: |
GCR 15 Bearing Steel |
Type: |
One Way Bearings |
Torque (Nm）: |
44-20000 |
Weight (Kg): |
0.9-91 |
Bore Size(mm): |
12-120 |
Name: |
GCZ-A One Direction Bearing Roller Type Clutch |
Material: |
GCR 15 Bearing Steel |
Type: |
One Way Bearings |
Torque (Nm）: |
44-20000 |
Weight (Kg): |
0.9-91 |
Bore Size(mm): |
12-120 |
GCZ-A One Direction Bearing Roller Type Clutch
Production introduction
Tapered roller bearing belongs to separate bearing, and the inner and outer rings of the bearing have tapered raceways. This type of bearing is divided into single row, double row and four row tapered roller bearings according to the number of rows of rollers installed. Single row tapered roller bearings can withstand radial load and axial load in a single direction. When the bearing bears radial load, an axial component will be generated, so another bearing that can bear the axial force in the opposite direction is needed to balance
Type GCZ-A is a roller type freewheel, self contained, sealed and bearing supported, using two 160 series bearings. Units are delivered oil lubricated.
A keyway is machined on the outer race for the connection to the drive member centered on its outside. Cover is used to close the unit. It is equipped with two screws for oil filling, drain and level.
This type extensive used in machinery system of conveyor, hoisting, packing, printing, papermaking, weaving, food and so on, to realize overrunning or indexing.
| Type |
NOMINAL TORQUE [N • m] |
OVERRUNNING LIMITING SPEED [r / min] |
DIMENSION IN CONTOUR [mm] | WEIGHT [kg] | ||||||||||
|
INNER RACE |
OUTTER RACE |
d [H7] | D [h7] | D1 | D2 | D3 | L | L1 | e | bn x tn | n - d1 | |||
| GCZ-A1262 | 44 | 1600 | 2800 | 12 | 62 | 42 | 72 | 85 | 43 | 42 | 2 | 4 x 1.8 | 3 - 5.5 | 0.90 |
| GCZ-A1568 | 100 | 1450 | 2600 | 15 | 68 | 47 | 78 | 92 | 55 | 52 | 4 | 5 x 2.3 | 3 - 5.5 | 1.30 |
| GCZ-A2075 | 151 | 1080 | 2300 | 20 | 75 | 55 | 85 | 98 | 59.5 | 57 | 3 | 6 x 2.8 | 4 - 5.5 | 1.70 |
| GCZ-A2590 | 230 | 840 | 1800 | 25 | 90 | 68 | 104 | 118 | 62.5 | 60 | 3 | 8 x 3.3 | 4 - 5.5 | 2.67 |
| GCZ-A30100 | 400 | 680 | 1600 | 30 | 100 | 75 | 114 | 128 | 70.5 | 68 | 3 | 8 x 3.3 | 6 - 6.6 | 3.50 |
| GCZ-A35110 | 580 | 620 | 1500 | 35 | 110 | 80 | 124 | 138 | 76.5 | 74 | 3.5 | 10 x 3.3 | 6 - 6.6 | 4.50 |
| GCZ-A40125 | 820 | 460 | 1300 | 40 | 125 | 90 | 142 | 160 | 88.0 | 86 | 3.5 | 12 x 3.3 | 6 - 9.0 | 6.90 |
| GCZ-A45130 | 900 | 400 | 1200 | 45 | 130 | 95 | 146 | 165 | 88.5 | 86 | 3.5 | 14 x 3.8 | 8 - 9.0 | 9.10 |
| GCZ-A50150 | 1700 | 320 | 1075 | 50 | 150 | 110 | 165 | 185 | 96.0 | 94 | 4 | 14 x 3.8 | 8 - 9.0 | 10.1 |
| GCZ-A55160 | 1890 | 300 | 1000 | 55 | 160 | 115 | 182 | 204 | 106.5 | 104 | 4 | 16 x 4.3 | 8 - 11 | 13.1 |
| GCZ-A60170 | 2520 | 260 | 950 | 60 | 170 | 125 | 192 | 214 | 116.0 | 114 | 4 | 18 x 4.4 | 10 - 11 | 15.6 |
| GCZ-A70190 | 4320 | 220 | 875 | 70 | 190 | 140 | 212 | 234 | 136.5 | 134 | 4 | 20 x 4.9 | 10 - 11 | 20.4 |
| GCZ-A80210 | 7285 | 200 | 800 | 80 | 210 | 160 | 232 | 254 | 146.5 | 144 | 4 | 22 x 5.4 | 10 - 11 | 25.2 |
| GCZ-A90230 | 9440 | 180 | 725 | 90 | 230 | 180 | 254 | 278 | 161.0 | 158 | 4 | 25 x 5.4 | 10 - 14 | 37.95 |
| GCZ-A100270 | 12800 | 140 | 625 | 100 | 270 | 210 | 305 | 335 | 184.0 | 182 | 5 | 28 x 6.4 | 10 - 18 | 71.04 |
| GCZ-A120310 | 20000 | 100 | 500 | 120 | 310 | 240 | 345 | 375 | 214.0 | 212 | 5 | 32 x 7.4 | 12 - 18 | 91.0 |
