ASNU80 One Way Clutch Roller Bearing for Industrial Fans

Name: ASNU80 One Way Clutch Roller Bearing for Industrial Fans
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: ASNU 80
Price: 7.10 USD
Availability: InStock

Product Details

Place of Origin: Jiangsu, China

Brand Name: SUMA

Model Number: ASNU 80

Payment & Shipping Terms

Minimum Order Quantity: 1

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            one way clutch bearing for industrial fans, industrial fan roller bearing with warranty, one way bearing for industrial equipment


Type:	SPRAG	Precision Rating:	P6
Seals Type:	Sealed	Structure:	Roller Type
Material:	GCr15	Model:	ASNU80
Inner Diameter:	80mm	Outer Diameter:	170mm
Torque Capacity:	3275Nm	Weight:	6.09kg
Overrunning Speed Max:	850 Min-1	Overrunning Speed Min:	550 Min-1
Drag Torque:	180 Ncm	Bearing Supported:	No
Lubrication Required:	Yes

Type:	SPRAG
Precision Rating:	P6
Seals Type:	Sealed
Structure:	Roller Type
Material:	GCr15
Model:	ASNU80
Inner Diameter:	80mm
Outer Diameter:	170mm
Torque Capacity:	3275Nm
Weight:	6.09kg
Overrunning Speed Max:	850 Min-1
Overrunning Speed Min:	550 Min-1
Drag Torque:	180 Ncm
Bearing Supported:	No
Lubrication Required:	Yes

Description

ASNU80 One Way Clutch Roller Bearing for Industrial Fans

ASNU80 Cam Clutch One Way Clutch Roller Bearing for Fan

Product Specifications

Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works, Energy & Mining
Type	SPRAG
Precision Rating	P6
Seals Type	Sealed
Product Name	One Way Clutch Roller Bearing
Bearing Supported	No
Stock	Rich
OEM	Accept
Delivery Time	5-7 days after order is confirmed
Package	Wooden package or customizable
Structure	Roller type
Material	GCr15

Key Features

Roller type freewheel non-bearing supported
Requires separate bearings to support axial and radial loads
Lubrication and sealing provided by installation
Inner race keyed to the shaft
Outer race has positive n6 tolerance for press fit in H7 housing

Technical Parameters

Product Name	One Way Clutch Bearing
Model	ASNU80
Material	Chrome steel GCr15
Inner Diameter	80mm
Outer Diameter	170mm
Torque Capacity	3275Nm
Weight	6.09kg
Package	Carton Box / Wooden box
Payment Terms	TT, L/C, D/A, D/P, Western Union
Delivery Time	2-4 days for sample, 7 days for bulk orders

Performance Specifications

ASNU80 Model Highlighted: 3275Nm torque capacity, 550-850 overrunning speeds, 170mm outer diameter, 6.09kg weight

Product Images

Manufacturer Information

Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) specializes in producing various cam clutches, one way bearings, backstop clutches, and overrunning clutches with high technology.

We follow "Best Quality, Best Price, Fast Delivery, Best Service" to satisfy all customers.

Production Process

Client Visits

Frequently Asked Questions

How do you pack the goods?

Total less than 25 KG: Each in white box + 19*18*9cm box + 29*28*19CM carton box
Total Weight over 100KG: Carton box + Wooden Box / Wooden Pallet

Can I get samples from you?

We highly encourage requesting samples for quality inspection.

Can you promise timely delivery?

Small items: In stock
Medium Items: 10-15 Days
Big items: 20-25 Days
