NFR40 Roller One Way Bearing 40mm ID 110mm OD for Cement Hoist

Name: NFR40 Roller One Way Bearing 40mm ID 110mm OD for Cement Hoist
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: NFR40
Price: 7.10 USD
Availability: InStock

Product Details

Place of Origin: Jiangsu, China

Model Number: NFR40

Payment & Shipping Terms

Minimum Order Quantity: 1

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            40mm one way bearing for cement hoist, NFR40 roller bearing 110mm OD, one way bearing with warranty


Inner Diameter:	40mm	Outer Diameter:	110mm
Weight:	3.3kg	Torque:	1100Nm
Precision Rating:	P6	Number Of Row:	Double Row
Bore Size:	40 - 40.01 Mm	Seals Type:	Sealed
Overrunning Speed Inner:	1150 Rpm	Overrunning Speed Outer:	2600 Rpm
Thickness:	63mm	Structure:	Deep Groove
Type:	Roller, BALL	Bearing Support:	16011**
Material:	Steel

Inner Diameter:	40mm
Outer Diameter:	110mm
Weight:	3.3kg
Torque:	1100Nm
Precision Rating:	P6
Number Of Row:	Double Row
Bore Size:	40 - 40.01 Mm
Seals Type:	Sealed
Overrunning Speed Inner:	1150 Rpm
Overrunning Speed Outer:	2600 Rpm
Thickness:	63mm
Structure:	Deep Groove
Type:	Roller, BALL
Bearing Support:	16011**
Material:	Steel

Description

NFR40 Roller One Way Bearing 40mm ID 110mm OD for Cement Hoist

NFR40 Roller Type One Way Bearing As Backstop for Cement Hoist Machine

Product Attributes

Attribute	Value
Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Retail, Printing Shops, Construction works, Energy & Mining, Other
Precision Rating	P6
Number of Row	Double row
Model	NFR40
Inner Diameter	40mm
Outer Diameter	110mm
Weight	3.3kg
Torque	1100Nm
OEM	Accept
Port	Shanghai;Ningbo
Type	roller, BALL
Structure	Deep Groove
Bore Size	40 - 40.01 mm
Seals Type	sealed

Product Description

Type NFR is a bearing supported roller type freewheel without any sealing. Lubrication and sealing must be provided by the installation. Standard lubrication is oil. Size 8 to 20 units use steel on steel bearing support from the inner race. Above size 20, two 160...Series ball bearings are used, giving a higher overrunning speed capacity.

The inner race is keyed to the shaft. The outer race has a positive n6 tolerance to give a press fit in a housing to H7. Additional side notches provide for positive torque transmission. The housing must be strong enough to not expand after assembly.

Technical Specifications

Parameter	Value
Model	NFR40
Torque (N.m)	1100
Overrunning Speeds (rpm)	Inner Race: 1150 Outer Race: 2600
Dimensions (mm)	Bore Size: 40 Outer Race Size: 110 Thickness: 63
Weight (Kg)	3.3

Detailed Parameters
