FSO500 Sprag One Way Clutch Bearing 30mm ID 107.95mm OD

Name: FSO500 Sprag One Way Clutch Bearing 30mm ID 107.95mm OD
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: FSO500 / HPI 500 / FSO500GR
Price: 7.10 USD
Availability: InStock

Product Details

Place of Origin: Jiangsu, China

Brand Name: SUMA or OEM

Model Number: FSO500 / HPI 500 / FSO500GR

Payment & Shipping Terms

Minimum Order Quantity: 1

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            30mm one way clutch bearing, sprag clutch bearing 107.95mm OD, FSO500 one way bearing with warranty


Type:	Sprag	Precision Rating:	P0
Seals Type:	SEALED	Material:	GCr15
Inner Diameter:	30mm	Outer Diameter:	107.95mm
Torque Capacity:	1621Nm	Weight:	4.8kg
Overrunning Speed:	2500/800 Min-1	Bearing Support:	Self-contained
Ball Bearings:	2	Model:	FSO500
Torque Drag:	31 Ncm	Size:	30-8x7
Dimensions:	88.9mm X 107.95mm X 85.73mm

Type:	Sprag
Precision Rating:	P0
Seals Type:	SEALED
Material:	GCr15
Inner Diameter:	30mm
Outer Diameter:	107.95mm
Torque Capacity:	1621Nm
Weight:	4.8kg
Overrunning Speed:	2500/800 Min-1
Bearing Support:	Self-contained
Ball Bearings:	2
Model:	FSO500
Torque Drag:	31 Ncm
Size:	30-8x7
Dimensions:	88.9mm X 107.95mm X 85.73mm

Description

FSO500 Sprag One Way Clutch Bearing 30mm ID 107.95mm OD

HPI500 FSO500 FSO 500 GR Anti Reversing One Way Clutch Sprag Freewheel Bearing

Product Specifications

Attribute	Value
Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction works, Energy & Mining
Type	sprag, Sprag
Precision Rating	P0
Seals Type	SEALED
Product name	FSO500 one way clutch
OEM	Accept
Delivery Time	7-10 Days
Package	Carton Box
Material	GCr15
ID	30mm
OD	107.95mm
Torque capacity	1621Nm

Product Description

The HPI500 FSO500 Anti Reversing One Way Clutch Sprag Freewheel Bearing is a sealed, sprag type freewheel with two ball bearings, designed for reliable performance in demanding industrial applications.

Key Features

Type FSO sealed sprag freewheel design
Self-contained, bearing supported construction
High-quality GCr15 material
30mm inner diameter / 107.95mm outer diameter
High torque capacity of 1621Nm
Weight: 4.8kg

Technical Specifications

Product name	one way clutch sprag freewheel
Model	FSO500
Material	GCr15
Inner diameter	30mm
Outer diameter	107.95mm
Torque capacity	1621Nm
Weight	4.8kg
Application	Gear Units, Inclinded conveyor, Electric motors, elevators
Package	Carton Box / Wooden box or customizable
Payment terms	TT. L/C, D/A,D/P,Western Union
Delivery time	10-15 Days

Product Images

Manufacturer Information

Changzhou Suma Precision Machinery Co., Ltd (Changzhou Tianniu Clutch Factory) is a manufacturer specialized in producing various cam clutches, one way bearings, one way clutches, backstop clutches, overrunning clutches and other bearings with high technology.

We follow "Best Quality, Best Price, Fast Delivery, Best Service" to satisfy all our customers.

Frequently Asked Questions

Q: How do you pack the goods?

- Total less than 25 KG: Each in white box + 19*18*9cm box + 29*28*19CM carton box
- Total Weight over 100KG: Carton box + Wooden Box / Wooden Pallet

Q: Can I get the samples from you?

A: It is highly encouraged to ask for the samples for quality check.

Q: Can you promise to deliver the goods in time?

- Small items: In stock
- Medium Items: 10-15 Days
- Big items: 20-25 Days
