CKS70 Two Way Bearings Overrunning Clutch Warner Replacement Customized

Name: CKS70 Two Way Bearings Overrunning Clutch Warner Replacement Customized
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: CKS series
Price: 7.10 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Tianniu

Certification: ISO-9001

Model Number: CKS series

Payment & Shipping Terms

Minimum Order Quantity: 1 pcs

Price: Negotiable

Packaging Details: Cartons by sea shipping by airplane

Delivery Time: 5-10working days

Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P

Supply Ability: 10000 per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                    CK-A1747 Tianniu, CK-A2052 Tianniu, one way sprag clutch bearing For CNC Lathe Tianniu


Name:	CKS70 Two Way Bearings Overrunning Clutch	Material:	GCR 15 Bearing Steel
Type:	One Way Bearings	OD:	32-90mm
Torque (Nm）:	20-300	Bore Size(mm):	10-45mm

Name:	CKS70 Two Way Bearings Overrunning Clutch
Material:	GCR 15 Bearing Steel
Type:	One Way Bearings
OD:	32-90mm
Torque (Nm）:	20-300
Bore Size(mm):	10-45mm

Description

CKS70 Two Way Bearings Overrunning Clutch Warner Replacement Customized

CKS70 Two Way Bearings Overrunning Clutch Warner Replacement Customized

Production introduction

CKS two way overrunning clutch,it drive shaft end shaft hole,the other end of the shaft hole driven shaft.the

outer ring, drive shaft clockwise or the reverse When the needle turns, driven shaft synchronous rotation, but w

hen the driven shaft at the role of external torque, clockwise and anti-clockwise rotation.With ball screw Vice or

its components supporting it,as to prevent reverse agencies,can also be used alone as a precise positioning,or

cut off the transmission torque moment pass. Used for printing Brush machinery, filling machinery, lifting transp

ortation machinery, all kinds of non-standard equipment and mechanical transmission test bench.

Products Parameters

Model	Clutch Size						Flange Size						Torque capacity
Model	d	D	T	C	b1	t1	D1	D2	D3	H	h	d1	(N.m)
CKS70(42)X58-10	10	32	51	20	3	1.4	70	55	42	58	11	6.5	20
CKS75(45)X58-10	10	35	52	20	3	1.4	75	60	45	58	11	6.5	20
CKS75(45)X58-12	12	35	51	20	4	1.8	75	60	45	58	11	6.5	20
CKS75(45)X58-15	15	35	51	20	3	1.4	75	60	45	58	11	6.5	20
CKS95(57)X78-17	17	47	70	27	5	2.3	95	75	57	78	13	8.5	50
CKS105(62)X78-20	20	52	70	27	6	2.8	105	84	62	78	16	10.5	100
CKS115(74)X78-20	20	62	70	27	6	3.3	115	95	74	78	16	10.5	100
CKS115(74)X78-25	25	62	80	32	8	3.3	115	95	74	88	16	10.5	120
CKS125(84)X100- 30	30	72	90	37	8	3.3	125	105	84	100	16	10.5	150
CKS132(88)X100-30	30	75	90	35	8	3.3	132	110	84	100	16	10.5	150
CKS145(94)X110-35	35	80	100	40	10	3.3	145	120	94	110	20	13	200
CKS155(102)X110-40	40	85	100	40	12	3.3	155	128	102	110	20	13	250
CKS160(108)X120-45	45	90	110	45	14	3.8	160	134	108	120	20	13	300

CKS70 Two Way Bearings Overrunning Clutch Warner Replacement Customized 0
