Product Details
Place of Origin: China
Brand Name: Tianniu
Certification: ISO9001
Model Number: RSBW series
Payment & Shipping Terms
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Cartons by sea shipping by airplane
Delivery Time: 10-15 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability: 10000 per month
Packaging: |
Carton Box |
MOQ: |
1 Piece |
Material: |
Steel |
OEM/ODM: |
Available |
Application: |
Automotive |
Warranty: |
1 Year |
Size: |
Customized |
Surface Treatment: |
Polishing |
Packaging: |
Carton Box |
MOQ: |
1 Piece |
Material: |
Steel |
OEM/ODM: |
Available |
Application: |
Automotive |
Warranty: |
1 Year |
Size: |
Customized |
Surface Treatment: |
Polishing |
Overrunning Clutch is a safety clutch system, also known as backstop clutches, used to prevent the reverse rotation of the system in certain applications. It is usually used in assembly lines, packaging machines, etc. This backstop mechanism can be customized to meet different requirements with various sizes, surface treatments and OEM/ODM services. Polishing surface treatment is available and the MOQ is 1 piece.
| Size | TK1 | Overrunning speeds | Weight |
Drag torque |
||||||||||
| dH7 | Nimax2) | Namax3) | Dh7 | D5 | D6 | D3 | Z | O | L | f | s | (kg) | TR | |
| (mm) | (Nm ) | (min-1) | (min-1) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (Ncm) | |
| 12 | 17 | 3100 | 6000 | 47 | 28 | 20 | 38 | 3 | 5.5 | 20 | 0.5 | 4.5 | 0.21 | 0.7 |
| 15 | 55 | 2300 | 5400 | 55 | 37 | 26 | 45 | 3 | 5.5 | 30 | 0.8 | 4.5 | 0.44 | 3.5 |
| 20 | 146 | 2000 | 3600 | 68 | 50 | 35 | 58 | 4 | 5.5 | 34 | 0.8 | 5.5 | 0.7 | 8.4 |
| 25 | 285 | 1700 | 2600 | 90 | 68 | 45 | 7 | 6 | 5.5 | 37 | 1 | 6.5 | 1.3 | 14 |
| 30 | 500 | 1500 | 2100 | 100 | 75 | 50 | 87 | 6 | 6.6 | 44 | 1 | 6.5 | 2 | 23 |
| 35 | 720 | 1300 | 1950 | 110 | 80 | 55 | 96 | 6 | 6.6 | 48 | 1 | 6.5 | 2.6 | 60 |
| 40 | 1030 | 1200 | 1700 | 125 | 90 | 60 | 108 | 6 | 9 | 56 | 1.5 | 7.6 | 3.9 | 72 |
| 45 | 1125 | 1050 | 1500 | 130 | 95 | 65 | 112 | 8 | 9 | 56 | 1.5 | 7.6 | 4 | 140 |
| 50 | 2150 | 950 | 1300 | 150 | 110 | 75 | 132 | 8 | 9 | 63 | 1.5 | 7.6 | 6 | 180 |
| 55 | 2675 | 850 | 1200 | 160 | 115 | 82 | 138 | 8 | 11 | 67 | 2 | 7.6 | 7.2 | 190 |
| 60 | 3500 | 800 | 1100 | 170 | 125 | 90 | 150 | 10 | 11 | 78 | 2 | 7.6 | 9.2 | 240 |
| 70 | 5813 | 650 | 900 | 190 | 140 | 100 | 165 | 10 | 11 | 95 | 2.5 | 7.6 | 11.8 | 320 |
Tianniu's RSBW series of Overrunning Clutches are designed for a variety of applications. With ISO9001 certification, these one-way clutches are available at a negotiable price. Depending on customer needs, the product can be shipped in cartons via sea or air. Delivery time is usually within 10-15 working days. Payment can be made through T/T, Western Union, MoneyGram, L/C, D/A, or D/P. With a capacity of up to 10000 per month, the size can be customized for each order. Surface treatment is done with polishing. OEM/ODM services are available and each order is shipped in a carton box.
Brand Name: Tianniu
Model Number: RSBW series
Place of Origin: China
Certification: ISO9001
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Cartons by sea shipping by airplane
Delivery Time: 10-15 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability: 10000 per month
MOQ: 1 Piece
Material: Steel
Warranty: 1 Year
Product Type: Overrunning Clutch
Application: Automotive
Tianniu RSBW Series Overrunning Clutch System is specially designed for Automotive industry, providing safety and reliable performance. It offers long-term reliability, with its high-quality steel material and ISO9001 certification. It also comes with 1 year warranty for your peace of mind.
Besides its robust construction, the Overrunning Clutch System also features a competitive price and flexible MOQ from 1 pcs. Delivery is 10-15 working days and payment terms are T/T, Western Union, MoneyGram, L/C, D/A, D/P.
If you are looking for a reliable and safe Overrunning Clutch System for Automotive, Tianniu RSBW Series is definitely your best choice!
We offer technical support and services for our Overrunning Clutch product. Our experienced team of professionals can assist you in identifying the right product and/or troubleshooting any issues you may be experiencing. We are available to answer any questions you may have about installation, operation, maintenance, and more.
Our support services include:
We are committed to providing the highest quality service and support for our Overrunning Clutch product. If you have any questions or would like to learn more about our product and services, please feel free to contact us.
Packaging and Shipping of Overrunning Clutch:
The Overrunning Clutch is packaged in a safe and secure manner to protect against any damage or breakage during shipping. The package is designed to withstand the rigors of the shipping process. To ensure the product is properly protected, it is placed in a cardboard box with foam inserts. The box is then sealed with tape and marked with the product name and address.
The Overrunning Clutch is then shipped via a reputable courier service. Prior to shipment, the package is inspected to ensure it is in good condition. Upon delivery, the package is inspected for any signs of damage or breakage.
