Aluminum Shaft Coupling 25mm 35mm 50mm 60mm Double Diaphragm Clamping

Name: Aluminum Shaft Coupling 25mm 35mm 50mm 60mm Double Diaphragm Clamping
Brand: Changzhou Tianniu Transmission Equipment Co., Ltd
SKU: GL series
Price: 149.10 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Tianniu

Certification: ISO-9001

Model Number: GL series

Payment & Shipping Terms

Minimum Order Quantity: 2 pcs

Price: Negotiable

Packaging Details: Cartons by sea shipping by Airplane

Delivery Time: 5-7 working days

Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A, D/P

Supply Ability: 10000 per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            shaft coupling 35mm, shaft coupling 60mm, 50mm shaft coupling


Model:	GL Double Diaphragm Clamping Coupling	Material:	Aluminum Alloy
Bore Size:	12-50mm	Warranty:	12 Months
Elastomer Materia:	PA66	Surface Treatment:	Anodic Oxidation Treatment
Type:	Double Diaphragm Clamping Coupling

Model:	GL Double Diaphragm Clamping Coupling
Material:	Aluminum Alloy
Bore Size:	12-50mm
Warranty:	12 Months
Elastomer Materia:	PA66
Surface Treatment:	Anodic Oxidation Treatment
Type:	Double Diaphragm Clamping Coupling

Description

Aluminum Shaft Coupling 25mm 35mm 50mm 60mm Double Diaphragm Clamping

GL Aluminum alloy double diaphragm clamping coupling

Products Features

Shaft Coupling is a mechanical component used to connect the driving shaft and driven shaft in different mechanisms to rotate together and transmit motion and torque. In addition to transmitting motion, the coupling can also compensate the offset (including axial offset, radial offset, angular offset or comprehensive offset) between the two shafts due to inaccurate manufacturing and installation, deformation or thermal expansion during operation, mitigate impact and vibration absorption, and play the role of overload protection to achieve stable motion transmission.

The following is the advantage of GL Aluminum alloy double diaphragm clamping shaft couping,

> High torque rigidity, can accurately control the rotation of the shaft, can carry out high-precision control
> Designed for servo and stepping motor
> No gap between the shaft and sleeve connection, general for positive and negative rotation
> Low inertia, suitable for high speed operation
> The diaphragm is made of spring steel with excellent fatigue resistance
> Fastening method of clamping screw

Products Parameters

Aluminum Shaft Coupling 25mm 35mm 50mm 60mm Double Diaphragm Clamping 0

model parameter	common bore diameter d1,d2	ΦD	L	LF	LP	d3	S	F	M	tightening screw torque (N.M)
GL-19X27	3,4,5,6,6.35,7,8	19	27	9.1	5.2	Φ9	1.8	3.3	M2.5	1
GL-26X35	5,6,6.35,7,8,9,9.525,10,11,12,14	26	35	11.65	6.5	Φ12.5	2.6	3.9	M3	1.5
GL-32X41	5,6,6.35,7,8,9,9.525,10,11,12,12.7,14,15,	32	45	12.25	9.5	Φ15	3.5	3.85	M3	1.5
GL-34X45	5,6,6.35,7,8,9,9.525,10,11,12,12.7,14,15,16	34	45	14.25	9.5	Φ16	4.5	4.85	M4	2.5
GL-39X50	8,9,9.525,10,11,12,12.7,14,15,16,17,18,19	39	50	14.9	11.2	Φ9.3	4.5	5	M4	2.5
GL-44X50	8,9,9.525,10,11,12,12.7,14,15,16,17,18,19,20,22	44	50	14.9	11.2	Φ2.5	4.5	5	M4	2.5
GL-50X63	8,9,9.525,10,11,12,12.7,14,15,16,17,18,19,20, 22,24,25	50	63	20.6	12.5	Φ23	4.8	6	M5	7
GL-56X64	10,12,14,15,16,17,18,19,20,22,24,25,28,30,32	56	64	19.75	13.5	Φ2.5	5.5	6.4	M5	7
GL-68X75	12,14,15,16,17,18,19,20,22,24,25,28,30,32,35,38	68	75	23.35	15.7	Φ38.3	6.3	7.7	M6	12
GL-82X98	17,18,19,20,22,24,25,28,30,32,35,38,40,42	82	98	30	22	Φ45.5	8	9.7	M8	20

model parameter	Rated torque (N.M)*	allowable eccentricity (mm)*	allowable deflection angle (°)*	allowable axial deviation (mm)*	maximum speed rpm	static torsional stiffness (N.M/rad)	moment of inertia (Kg.M2)	Material of shaft sleeve	Material of shrapnel	surface treatment	weight (g)
GL-19X27	1	0.12	1.5	±0.18	10000	170	9.1x10-7	High strength aluminum alloy	SUS304Spring steel	Anodizing treatment	14.6
GL-26X35	1.5	0.15	1.5	±0.3	10000	820	3.0x10-6				37
GL-32X41	2	0.17	1.5	±0.36	10000	1750	1.0x10-5				67
GL-34X45	3	0.17	1.5	±0.36	10000	1860	1.1x10-5				77
GL-39X50	6	0.22	1.5	±0.45	10000	2860	3.0x10-5				118
GL-44X50	9	0.22	1.5	±0.54	10000	3300	3.8x10-5				144
GL-50X63	18	0.1	1.5	±0.54	10000	3300	3.0x10-5				235
GL-56X64	25	0.27	1.5	±0.72	10000	9480	1.6x10-4				318
GL-68X75	60	0.31	1.5	±0.8	9000	19000	2.0x10-4				492
GL-82X98	100	0.55	1.5	±0.8	8000	28450	2.5x10-4				1013
