Rigid Clamping Aluminum Metric Shaft Coupling High Torque GNC

Rigid Clamping Aluminum Alloy Shaft Coupling Metric With High Torque

Products Features

The flanged coupling is a rigid coupling, which is to connect two half-couplings with flanges to the two shafts with ordinary flat keys, and then use bolts to connect the two half-couplings into one to transmit motion. and torque. This kind of coupling has two main structural forms: 1. Relying on the hinged hole to use bolts to achieve the alignment of the two shafts and relying on the bolt rod to withstand extrusion and shearing to transmit torque; 2. relying on a half-coupling on the The shoulder is aligned with the groove on the other coupling half. The bolts connecting the two half-couplings can use ordinary bolts of grade B and B, and the torque is transmitted by the friction torque of the joint surfaces of the two half-couplings.

The material of the flange coupling can be gray cast iron or carbon steel, and cast steel or forged steel shall be used for heavy load or when the peripheral speed is greater than 30 m/s. The flange coupling has high requirements on the neutrality of the two shafts. When there is relative displacement between the two shafts, additional loads will be caused in the parts and the working conditions will be deteriorated. This is its main disadvantage. However, due to the simple structure, low cost and large torque transmission, when the rotation speed is low, there is no impact, and the rigidity of the shaft is large

>Integrated structure, the overall use of high-strength aluminum alloy materials
>High torque, high rigidity
>The rigid type basically does not allow eccentricity, so it must be fully adjusted in use
>Fastening method of setscrew screw

Products Parameters
